120kg mobile Self-propelled mini scissor lift elevator

120kg mobile Self-propelled mini scissor lift elevator

    • 120kg mobile Self-propelled mini scissor lift elevator
    • 120kg mobile Self-propelled mini scissor lift elevator
    • 120kg mobile Self-propelled mini scissor lift elevator
    • 120kg mobile Self-propelled mini scissor lift elevator
    • 120kg mobile Self-propelled mini scissor lift elevator
  • 120kg mobile Self-propelled mini scissor lift elevator

    Product Details:

    Place of Origin: China
    Brand Name: Higher ster
    Certification: ISO,ce
    Model Number: 3m

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: USD2000-10000/set
    Packaging Details: The normal package is pe film or wooden box for Mobile Scissor lift
    Delivery Time: 14 working day after deposite
    Supply Ability: 30set/month
    Contact Now
    Detailed Product Description
    Lift Mechanism:: Scissor Lift Max. Lifting Height: 3m
    Min. Lifting Height: 0.5m Rated Loading Capacity:: 240kgs


    Product Description

    General Introduction of electric lift platform scissor lifter

    1. Load capacity:120kg 230kg 300kg 500kg 1000kg etc.
    2. Lifting height: 4m-26m
    3. Drive power: AC /DC/Diesel/Gasoline.
    4. Applications: aerial installation, maintenance, clean at the construction sites, workshops, warehouse, station, hotel, airport, wharf, gas station and stadium etc.
    5. Custom-made according to the requirement

    6. Advantage: Electric lift makes low noise and no emission when working. 90-degree steering can run in both high and low speeds, enable electric lift work in small space.



    Safety protection

    1. Explosion-proof valves: protect hydraulic pipe, anti-hydraulic pipe rupture
    2. Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure.
    3. Emergency decline valve: it can go down when you meet an emergency.

    Model
    Model
    Capacity
    (kg)
    Table size (mm)
    Max. height
    (mm)
    Power
    (kw)
    Total dimension
    (mm)
    Machine weight
    (kg)
    LXSJY0.3-4
    300
    1650*750
    4000
    2.2
    2100*950*2050
    400
    LXSJY0.3-6
    300
    1650*750
    6000
    2.2
    2100*950*2120
    650
    LXSJY0.3-8
    300
    1800*900
    8000
    2.2
    2200*1260*2450
    1200
    LXSJY0.3-10
    300
    2110*1220
    1000
    2.2
    2600*1550*2400
    1500
    LXSJY0.3-12
    300
    2550*1500
    12000
    2.2
    3150*2000*2850
    2850
    LXSJY0.3-14
    300
    3000*1600
    14000
    2.2
    3550*2120*2850
    3000
    LXSJY0.3-16
    300
    3200*1600
    16000
    3.0
    3890*2120*3030
    3900
    LXSJY0.3-18
    300
    3200*1600
    18000
    3.0
    4300*2120*3250
    4300
    LXSJY0.5-10
    500
    2110*1220
    10000
    2.2
    2700*1550*2450
    1600
    LXSJY0.5-12
    500
    2550*1500
    12000
    2.2
    3160*2000*2850
    2600
    LXSJY0.5-14
    500
    3000*1600
    14000
    2.2
    3550*2120*2850
    3100
    LXSJY0.5-18
    500
    3210*1600
    18000
    3.0
    3890*2120*3030
    4300
    LXSJY1.0-8
    1000
    2000*1220
    8000
    3.0
    2600*1550*2640
    1800
    LXSJY1.0-10
    1000
    2220*1200
    10000
    3.0
    2820*1720*2850
    2380
    LXSJY1.0-12
    1000
    2600*1500
    12000
    3.0
    3200*2015*3090
    3580
    LXSJY1.0-14
    1000
    3000*1600
    14000
    3.0
    3550*2120*2850
    3800
    Remarks:we accept customized design,pls advise Max.Load capacity ,Max.Lifting Height and where do you use.
    All diemensions is subject to the real machine.

    Detailed Images
    120kg mobile Self-propelled mini scissor lift elevator

    Standard Configuration

    AC 380V
    Emergency lowering valve
    Leveling device with supporting screw
    Waterproof electric box
    Emergency stop button

    Optional Configuration:

    AC 220V (for 6m – 11m platform),DC,
    AC/DC, Disesel,Gasoline
    Explosion proof electric control system
    Rubber solid tire
    Extension platform

    Self-propelled electric device

    Packing & Delivery

    Packing Details.

    The normal package is pe film or wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

    120kg mobile Self-propelled mini scissor lift elevator
    Factory Images
    120kg mobile Self-propelled mini scissor lift elevator
    120kg mobile Self-propelled mini scissor lift elevator


    Our Service


    1. Service concept: Exceed clients’ expectation.
    2. Presale service: Free comprehensive and detailed technology consultancy in construction sites, referential programs for construction equipment and the most suitable product program. View our Factory.
    3. In sale service: We provide free guidance of installation and debugging and free training of operation, care and maintenance.
    4. After-sale service: One-year warranty service of whole machine and lifetime maintenance; regularly markets visits and free guidance of whole machine’s maintenance and reparations.
    5. Quick responses: 24hours technical support by email, telephone or video online and assist you to solve the problem in a short time.
    6. Parts supply: we have a complete parts supply network and can guarantee sufficient parts reserves and timely supply.
